Course: Makefile-based workflow for Lattice

Learn to convert a Lattice iCEcube2 GUI project into a Makefile-based workflow. Manage your FPGA implementation project entirely from the command line.

Category: Tags: , ,

Description

Graphical user interface (GUI) tools are great for setting up an FPGA project. With the guidance of the “wizard” setup assistant, getting started quickly is easy.

However, a script-based design flow is more convenient as the project evolves beyond the initial stage. That’s especially true if several people are collaborating on the code.

Here are some of the reasons why companies prefer scripts and Makefiles:

  1. You can commit a script to your version control system, meaning that someone else can check out the code and reproduce your results without knowing which button sequences to click in the GUI.
  2. The script serves as documentation. You can always go back and find out exactly how each implementation step was started.
  3. It saves time in the long run. You can’t possibly click checkboxes and hit buttons as fast as a Makefile can start the programs to get you the results.

In this course, we grab a GUI-based Lattice iCEstick FPGA project from the membership portal and port it to a script-based flow. We will use a Makefile because it’s an industry standard that has existed for over 40 years, and it’s not going away anytime soon.

I’m showing you how to do it for Lattice FPGAs, but the method is the same for other FPGA vendors. And even though Make is a Unix tool, it works just as well with Windows (I’m using Windows).

Finally, we will have an FPGA project we can manage entirely from the command line. For example, by typing, make synth to synthesize, make hw to generate the bitfile, or make prog to program the FPGA.

This course is only available in the VHDLwhiz Membership.

The membership subscription gives you access to this and many other courses and VHDL resources.

You pay monthly to access the membership and can cancel the automatic renewal anytime. There is no lock-in period or hidden fees.

Hardware used in the course

Software used in the course

I am using Windows in the course. All the other software is available for free for Windows and Linux:

Notice: free educational license required

Lattice Semiconductor now charges over $350/year for the iCEcube2 software.

Fortunately, VHDLwhiz, in cooperation with Lattice, offers a 1-year educational license for iCEcube2 to customers who purchase a course that uses the iCE40 FPGA.

Reply to the purchase confirmation email to request a free license.

Course outline

Number of lessons:
12
Average video duration:
8m06s
Total video duration:
1h37m

The overview below shows the lessons in this course.

video lesson icon/default Created with Sketch.

1 - Why use Makefiles

Makefiles have been around for over 45 years, and they are not going away anytime soon.

video lesson icon/default Created with Sketch.

2 - Install the tools and get the example project

Set up your development environment quickly and easily.

video lesson icon/default Created with Sketch.

3 - Extract the commands from the iCEcube2 GUI

We can find the backend commands that the GUI uses in the transcript window.

video lesson icon/default Created with Sketch.

4 - Create implementation Makefile targets

In this lesson, we convert the extracted commands to targets and recipes in the Makefile.

video lesson icon/default Created with Sketch.

5 - Fix the synth target

The synthesis tool needs a few environment variables set to run without errors.

video lesson icon/default Created with Sketch.

6 - Fix the implementation targets

Let's see if we can get all the other Makefile targets working.

video lesson icon/default Created with Sketch.

7 - Program the FPGA using Make

We can invoke the Diamond programmer from the Makefile too.

video lesson icon/default Created with Sketch.

8 - Replace absolute paths with variables

Let's clean up this Makefile by using variables instead of hard-coded paths.

video lesson icon/default Created with Sketch.

9 - Synth prerequisite

We need to resynthesize whenever any of the source files change.

video lesson icon/default Created with Sketch.

10 - Implementation prerequisites

To rerun recipes only when the prerequisites have changed, we need to define new targets based on actual file names.

video lesson icon/default Created with Sketch.

11 - Clean target

Every Makefile should have a target that deletes the output and temporary files.

video lesson icon/default Created with Sketch.

12 - Help target

Let's make a nice help menu and set it as the default Makefile target.

This course is only available in the VHDLwhiz Membership.

The membership subscription gives you access to this and many other courses and VHDL resources.

You pay monthly to access the membership and can cancel the automatic renewal anytime. There is no lock-in period or hidden fees.
